This tone tweaker has a bevy of Gibson Custom Reissues, hand-built Strats and Marshall Amps
Mark Dewey is a former hair-rocker who''s graduated to the corporate world and Gibson Custom Shop Les Pauls. We were impressed by his collection of reissues, and intrigued by his custom-looking Strats, so we talked a little further with Mark about his collection and playing history. Here''s Mark''s collection, in his own words:
"This shows pretty much my backline of amps. All of my Marshalls have been modified by Alan Cyr of the Amp Exchange in Woodland Hills, California. He is the best amp guru alive for Marshall amps. They all have Mercury iron and just blister like nothing I have ever heard. I also have a Divided by 13 FTR 37 that Fred Taccone built for me a few years ago. His stuff is very unique -- super big clean sounds and a Marshall-Vox-like kind of brown sound on the click channel.
"I still pretty much plug a guitar directly into a Marshall and use the volume as a gain control for my main sound. Sometimes I will Y two amps together and have one DSL 100 with a slight delay and the other 59 HW head or 50 watt JCM 800 as pure tone.
"In the first photo, you also see a bunch of Gibson Custom guitars and a lineup of custom-built Strats. I got a little carried away with finding the best body wood/neck combinations last year so I built 15 of them. I also have experimented with a ton of pickup manufacturers like Seymour Custom winds, Suhr, DiMarzio, Nordstrand and a few others. My favorite pickup is pretty much a BurstBucker in a Les Paul Historic. They just sound like an open vowel waiting for your strings to vibrate. They are open, airy, clean, crunchy, stingy and have a ton of balls and low end while still being very clear and well-balanced.
"I have tried most [pickup] manufacturers cold and hot. For singles I like Seymour Duncan Custom calibrated set of Alnico 2: 6.5, 6.5 (RW Middle),6.5. MJ knows what she is doing and is great to work with. The John Suhr v60 LPs are equally as awesome for single coils. I have never tried a BurstBucker in a Strat, so I stick with Seymour or DiMarzio humbuckers. I like the five-way Superstrat wiring where you take two humbuckers and split the north coils on position 2 and the south coils on position 4. Since the pickups are reverse of each other this makes all five positions humbucking. I usually use a hi-pass filter on the volume so it rolls down clean and sparkly.
"Most of the guitars in my Gibson Custom Collection are newer reissues from 2001 to 2008. I made the jump and bought my first ‘59 from Willcutt’s guitars for $4000. It was a lot of money but quite frankly once I got the guitar, I realized I would rather have the guitar than the money so I was hooked and now have quite a few of them. The sound of a Custom Shop Les Paul is just so much better than anything else for rock guitar. I pretty much only play a Strat every now and then, especially for whammy bar gymnastics.
"Here are a few of my prime Custom Shop Les Pauls a few years ago. These are some of my favorites actually. However, I have never found one guitar or amp that does it all. There is no true "favorite” -- they are all different. I have never had a guitar I thought was "the one." Perhaps this is the devil’s snare for materialism. I also could not fathom buying a real ''59 because I already worry enough when I put a ''59 reissue in the back seat of my car. Imagine getting a $300,000 guitar stolen?
About Mark
Ice Water Mansion - Mark is second from left |
"This was a song I wrote about being scared of the dark – “Ghosts in the mirror”. I used my Marshall JCM 800 with a Fender Strat loaded with a humbucker with a boss compressor as a boost for lead schwing.
"I don’t play in a band anymore at the moment but I certainly play about two hours every day and all weekend. I have twp boys, ages four and five who both love guitars. My four-year-old plays drums like a man and also loves his plastic guitar collection. He has about ten, which makes me wonder if we are teaching him the sin of excess which I never meant to do myself.
"I guess at 43, I am done trying to make it big so I just focus on playing for the soul and the enjoyment. When you play a guitar, you forget about the wood in your hands and just kind of get “out there” and that is my bliss.
"I have also really enjoyed building, testing and working on gear too. I never thought I would even play guitar past 25, but I guess it now plays me!"
Listen to Mark''s Guitars
Mark was nice enough to share some YouTube clips of his guitars in action. Says Mark, "These are by no means anthing but my wife holding her sony camera sideways but you can sure hear the tone…"
- In this clip you can hear that ''59 Les Paul (Reissue) just bites like heck:
- Here is a Strat that I built which bites pretty good with Seymour Duncan Alnico 8s:
- Here is a ''58 Korina Explorer (Reissue) playing “Watchin over You,” one of my songs:
- Visit Mark online at https://www.myspace.com/markguitardewey
To join Mark as a Premier Collector, send an e-mail with photos and a description of your gear to rebecca@premierguitar.com |
Lollar Pickups introduces the Deluxe Foil humbucker, a medium-output pickup with a bright, punchy tone and wide frequency range. Featuring a unique retro design and 4-conductor lead wires for versatile wiring options, the Deluxe Foil is a drop-in replacement for Wide Range Humbuckers.
Based on Lollar’s popular single-coil Gold Foil design, the new Deluxe Foil has the same footprint as Lollar’s Regal humbucker - as well as the Fender Wide Range Humbucker – and it’s a drop-in replacement for any guitar routed for Wide Range Humbuckers such as the Telecaster Deluxe/Custom, ’72-style Tele Thinline and Starcaster.
Lollar’s Deluxe Foil is a medium-output humbucker that delivers a bright and punchy tone, with a glassy top end, plenty of shimmer, rich harmonic content, and expressive dynamic touch-sensitivity. Its larger dual-coil design allows the Deluxe Foil to capture a wider frequency range than many other pickup types, giving the pickup a full yet well-balanced voice with plenty of clarity and articulation.
The pickup comes with 4-conductor lead wires, so you can utilize split-coil wiring in addition to humbucker configuration. Its split-coil sound is a true representation of Lollar’s single-coil Gold Foil, giving players a huge variety of inspiring and musical sounds.
The Deluxe Foil’s great tone is mirrored by its evocative retro look: the cover design is based around mirror images of the “L” in the Lollar logo. Since the gold foil pickup design doesn’t require visible polepieces, Lollartook advantage of the opportunity to create a humbucker that looks as memorable as it sounds.
Deluxe Foil humbucker features include:
- 4-conductor lead wire for maximum flexibility in wiring/switching
- Medium output suited to a vast range of music styles
- Average DC resistance: Bridge 11.9k, Neck 10.5k
- Recommended Potentiometers: 500k
- Recommended Capacitor: 0.022μF
The Lollar Deluxe Foil is available for bridge and neck positions, in nickel, chrome, or gold cover finishes. Pricing is $225 per pickup ($235 for gold cover option).
For more information visit lollarguitars.com.
This simple passive mod will boost your guitar’s sweet-spot tones.
Hello and welcome back to Mod Garage. In this column, we’ll be taking a closer look at the “mid boost and scoop mod” for electric guitars from longtime California-based tech Dan Torres, whose Torres Engineering seems to be closed, at least on the internet. This mod is in the same family with the Gibson Varitone, Bill Lawrence’s Q-Filter, the Gresco Tone Qube (said to be used by SRV), John “Dawk” Stillwells’ MTC (used by Ritchie Blackmore), the Yamaha Focus Switch, and the Epiphone Tone Expressor, as well as many others. So, while it’s just one of the many variations of tone-shaping mods, I chose the Torres because this one sounds best to me, which simply has to do with the part values he chose.
Don’t let the name fool you, this is a purely passive device—nothing is going to be boosted. In general, you can’t increase anything with passive electronics that isn’t already there. Period. But you can reshape the tone by deemphasizing certain frequencies and making others more prominent (so … “boost” in guitar marketing language). Removing highs makes lows more apparent, and vice versa. In addition, the use of inductors (which create the magnetic field in a guitar circuit) and capacitors will create resonant peaks and valleys (bandpasses and notches), further coloring the overall tone. This type of bandpass filter only allows certain frequencies to pass through, while others are blocked, and it all works at unity gain.
“You can’t increase anything with passive electronics that isn’t already there … but you can reshape the tone by deemphasizing certain frequencies and making others more prominent.”
All the systems I mentioned above are doing more or less the same thing, using different approaches and slightly different component values. They are all meant to be updated tone controls. Our common tone circuit is usually a variable low-pass filter (aka treble-cut filter), which only allows the low frequencies to pass through, while the high frequencies get sent to ground via the tone cap. Most of these systems are LCR networks, which means that there is not only a capacitor (C), like on our standard tone controls, but also an inductor (L) and a resistor (R).
In general, all these systems are meant to control the midrange in order to scoop the mids, creating a mid-cut. This can be a cool sounding option, e.g. on a Strat for that mid-scooped neck and middle tone.
Dan Torres offered his “midrange kit” via an internet shop that is no longer online, same with his business website. The Torres design is a typical LCR network and looks like the illustration at the top of this column.
Dan’s design uses a 500k linear pot, a 1.5H inductor (L) with a 0.039 µF (39nF) cap (C), and a 220k resistor (R) in parallel. Let’s break down the parts piece by piece:
Any 500k linear pot will do the trick, in one of the rare scenarios where a linear pot works better in a passive guitar system than an audio pot.
(C) 0.039µF cap: This is kind of an odd value. Keeping production tolerances of up to 20 percent in mind, any value that is close will do, so you can use any small cap you want for this. I would prefer a small metallized film cap, and any voltage rating will do. If you want to stay as close as possible to the original design, use any 0.039 µF low-tolerance film cap.
(L) 1.5H inductor: The original design uses a Xicon 42TL021 inductor, which is easy to find and fairly priced. This one is also used in the Bill Lawrence Q-Filter design, the Gibson standard Varitone, and many other systems like this. It’s very small, so it will fit in virtually every electronic compartment of a guitar. It has a frequency range of 300 Hz up to 3.4 kHz, with a primary impedance of 4k ohms (that’s the one we want to use) and a secondary impedance of 600 ohms. Snip off the three secondary leads and the center tap of the primary side and use the two remaining outer primary leads; the primary side is marked with a “P.” On the pic, you can see the two leads you need marked in red, all other leads can be snipped off. You can connect the two remaining leads to the pot either way; it doesn’t matter which of them is going to ground when using it this way.
Drawing courtesy of singlecoil.com
(R) 220k: use a small axial metal film resistor (0.25 W), which is easy to find and is the quasi-standard.
Other designs use slightly different part values—the Bill Lawrence Q-filter has a 1.8H L, 0.02 µF C and 8k R, while the old RA Gresco Tone Qube from the ’80s has a 1.5H L, 0.0033 µF C, and a 180k R, so this is a wide field for experimentation to tweak it for your personal tone.
This mid-cut system can be put into any electric guitar not only as a master tone, but also together with a regular tone control or something like the Fender Greasebucket, or it can be assigned only to a certain pickup. It can be a great way to enhance your sonic palette, so give it a try.
That’s it! Next month, we’ll take a deeper look into how to fight feedback on a Telecaster. It’s a common issue, so stay tuned!
Until then ... keep on modding!
The two-in-one “sonic refractor” takes tremolo and wavefolding to radical new depths.
Pros: Huge range of usable sounds. Delicious distortion tones. Broadens your conception of what guitar can be.
Build quirks will turn some users off.
$279
Cosmodio Gravity Well
cosmod.io
Know what a wavefolder does to your guitar signal? If you don’t, that’s okay. I didn’t either until I started messing around with the all-analog Cosmodio Instruments Gravity Well. It’s a dual-effect pedal with a tremolo and wavefolder, the latter more widely used in synthesis that , at a certain threshold, shifts or inverts the direction the wave is traveling—in essence, folding it upon itself. Used together here, they make up what Cosmodio calls a sonic refractor.
Two Plus One
Gravity Well’s design and control set make it a charm to use. Two footswitches engage tremolo and wavefolder independently, and one of three toggle switches swaps the order of the effects. The two 3-way switches toggle different tone and voice options, from darker and thicker to brighter and more aggressive. (Mixing and matching with these two toggles yields great results.)
The wavefolder, which has an all-analog signal path bit a digitally controlled LFO, is controlled by knobs for both gain and volume, which provide enormous dynamic range. The LFO tremolo gets three knobs: speed, depth, and waveform. The first two are self-explanatory, but the latter offers switching between eight different tremolo waveforms. You’ll find standard sawtooth, triangle, square, and sine waves, but Cosmodio also included some wacko shapes: asymmetric swoop, ramp, sample and hold, and random. These weirder forms force truly weird relationships with the pedal, forcing your playing into increasingly unpredictable and bizarre territories.
This is all housed in a trippy, beautifully decorated Hammond 1590BB-sized enclosure, with in/out, expression pedal, and power jacks. I had concerns about the durability of the expression jack because it’s not sealed to its opening with an outer nut and washer, making it feel more susceptible to damage if a cable gets stepped on or jostled near the connection, as well as from moisture. After a look at the interior, though, the build seems sturdy as any I’ve seen.
Splatterhouse Audio
Cosmodio’s claim that the refractor is a “first-of-its-kind” modulation effect is pretty grand, but they have a point in that the wavefolder is rare-ish in the guitar domain and pairing it with tremolo creates some pretty foreign sounds. Barton McGuire, the Massachusetts-based builder behind Cosmodio, released a few videos that demonstrate, visually, how a wavefolder impacts your guitar’s signal—I highly suggest checking them out to understand some of the principles behind the effect (and to see an ’80s Muppet Babies-branded keyboard in action.)
By folding a waveform back on itself, rather than clipping it as a conventional distortion would, the wavefolder section produces colliding, reflecting overtones and harmonics. The resulting distortion is unique: It can sound lo-fi and broken in the low- to mid-gain range, or synthy and extraterrestrial when the gain is dimed. Add in the tremolo, and you’ve got a lot of sonic variables to play with.
Used independently, the tremolo effect is great, but the wavefolder is where the real fun is. With the gain at 12 o’clock, it mimics a vintage 1x10 tube amp cranked to the breaking point by a splatty germanium OD. A soft touch cleans up the signal really nicely, while maintaining the weirdness the wavefolder imparts to its signal. With forceful pick strokes at high gain, it functions like a unique fuzz-distortion hybrid with bizarre alien artifacts punching through the synthy goop.
One forum commenter suggested that the Gravity Well effect is often in charge as much the guitar itself, and that’s spot on at the pedal's extremes. Whatever you expect from your usual playing techniques tends to go out the window —generating instead crumbling, sputtering bursts of blubbering sound. Learning to respond to the pedal in these environments can redefine the guitar as an instrument, and that’s a big part of Gravity Well’s magic.
The Verdict
Gravity Well is the most fun I’ve had with a modulation pedal in a while. It strikes a brilliant balance between adventurous and useful, with a broad range of LFO modulations and a totally excellent oddball distortion. The combination of the two effects yields some of the coolest sounds I’ve heard from an electric guitar, and at $279, it’s a very reasonably priced journey to deeply inspiring corners you probably never expected your 6-string (or bass, or drums, or Muppet Babies Casio EP-10) to lead you to.
Kemper and Zilla announce the immediate availability of Zilla 2x12“ guitar cabs loaded with the acclaimed Kemper Kone speaker.
Zilla offers a variety of customization to the customers. On the dedicated Website, customers can choose material, color/tolex, size, and much more.
The sensation and joy of playing a guitar cabinet
Sometimes, when there’s no PA, there’s just a drumkit and a bass amp. When the creative juices flow and the riffs have to bounce back off the wall - that’s the moment when you long for a powerful guitar cabinet.
A guitar cabinet that provides „that“ well-known feel and gives you that kick-in-the-back experience. Because guitar cabinets can move some serious air. But these days cabinets also have to be comprehensive and modern in terms of being capable of delivering the dynamic and tonal nuances of the KEMPER PROFILER. So here it is: The ZILLA 2 x 12“ upright slant KONE cabinet.
These cabinets are designed in cooperation with the KEMPER sound designers and the great people from Zilla. Beauty is created out of decades of experience in building the finest guitar cabinets for the biggest guitar masters in the UK and the world over, combined with the digital guitar tone wizardry from the KEMPER labs. Loaded with the exquisit Kemper Kone speakers.
Now Kemper and Zilla bring this beautiful and powerful dream team for playing, rehearsing, and performing to the guitar players!
ABOUT THE KEMPER KONE SPEAKERS
The Kemper Kone is a 12“ full range speaker which is exclusively designed by Celestion for KEMPER. By simply activating the PROFILER’s well-known Monitor CabOff function the KEMPER Kone is switched from full-range mode to the Speaker Imprint Mode, which then exactly mimics one of 19 classic guitar speakers.
Since the intelligence of the speaker lies in the DSP of the PROFILER, you will be able to switch individual speaker imprints along with your favorite rigs, without needing to do extensive editing.
The Zilla KEMPER KONE loaded 2x12“ cabinets can be custom designed and ordered for an EU price of £675,- UK price of £775,- and US price of £800,- - all including shipping (excluding taxes outside of the UK).
For more information, please visit kemper-amps.com or zillacabs.com.
