The KISS co-founder partners with Gibson for second signature bass, a limited-edition run of 100 guitars.
Based on Gene’s heavily modified 1959 EB-0, the new Gene Simmons EB-0 Bass is the first 30.5” scale bass from the Gibson Custom Shop and the first bass the Custom Shop has produced in quantity. The Gene Simmons EB-0 Bass features a VOS finish in Ebony, as well as VOS hardware throughout, in addition, Gene made several modifications to his EB-0, including refinishing it, reshaping the neck to a custom profile, replacing the pickup with a later model Gibson unit, and relocating it much closer to the bridge, installing a custom pickguard, a fingerboard with Corian nut, adding binding, and changing the original tuners to Grovers. The bridge was also replaced with a high-mass model and can now be strung through-body or as a top-loaded bridge. All of these details are faithfully represented in the new Gene Simmons EB-0 Bass from Gibson Custom Shop. A custom hardshell case as well as case candy developed in collaboration with Gene is also included.
The Gene Simmons EB-0 Bass is inspired by the same Bass that Gene played with KISS in the 1970s. The new Gene Simmons EB-0 Bass is a limited-edition run of 100 guitars and is available worldwide at authorized Gibson Custom Shop dealers and via www.gibson.com. $6,999.00 USD.
Maxon OD-9 Overdrive Pedal
The Maxon OD-9 Overdrive Effects Pedal may look like your old favorite but that's where the similarity ends. Improved circuitry with a new chip yields the ultra-smooth dynamic overdrive guitarists crave. Drive and Level controls tweak the intensity and volume while the Hi-Boost/Hi-Cut tone controls adjust brightness. Features true bypass switching, a die-cast zinc case, and 3-year warranty. From subtle cries to shattering screams, the Maxon OD-9 delivers a huge range of tones.
Features
Improved circuitry with a new chip yields ultra-smooth dynamic overdrive
Drive and Level controls tweak the intensity and volume
Hi Boost/Hi Cut tone controls adjust brightness
True bypass switching
Die-cast zinc case
AC/DC operation (order optional Maxon AC210N adapter)
Product Specs
Input: 1/4" mono jack
Output: 1/4" mono jack
Power: 9V DC, 6 mA, center pin minus (not included)
Dimensions: (WxDxH) 74 mm x 124 mm x 54 mm
Weight: 580g
The magic is in the interactive nature of all these factors … and then some. (This list is for passive pickups and does not include many aspects of active pickups.) Sometimes I see pickups boiled down to only a few factors, and I do not think that is a sophisticated enough view of these complicated and potentially beautiful-sounding devices.
As an example, it is thought that most players have an idea of the sound that humbucking pickups with alnico 4 magnets that are wound to 7.8k make. They’re historically associated with PAF humbuckers, but those qualities don’t fully explain what gives those pickups character. For example, if the pickup’s wire is standard-size 42 gauge, at 5,000 turns the pickup would have a resistance of about 7.5k. If you use 42-gauge wire that is undersized (which is a common inconsistency) and 4,800 turns, the pickup would still be around 7.5k. Because of the wire diameter and different number of turns, the pickups would sound different even though it’s the same magnet and same resistance. The wire matters; 7.5k is just the resistance of both coils. Just as wire diameter varies, alnico 4 purchased from four manufacturers sounds four different ways, so you have to compensate for that in other design areas as well.
If you think about the sound of a Strat, there is a “whistle note” (or you can think of it as a “ping note”) in every note you play. Think about playing on the neck pickup on a Strat; you can hear that whistle sound in every note. The pickup without a load is resonating at about 11k and at about 15 dB. Fifteen decibels is a lot. Imagine adding 15 dB of 11k (high treble) to your vocal at a gig! The potentiometers on a Strat, and those are 250k (which is a fairly low value for a volume and tone control), calm down how loud the whistle note is. When these single-coil pickups are built well, this whistle note can be very musical. Just think of Robbie Blunt playing “Big Log” on Robert Plant’s 1983 album The Principle of Moments. For us at PRS, getting the whistle note to be the right frequency and the right volume is very important. It is believed, for good reason, that an old PAF pickup can sound very much like a single-coil Strat pickup. That is because of the frequency and volume of the whistle note coming out of these vintage pickups.
“In the end, it’s really simple. Do you like the sound of the pickup? Will it do the job that you’re looking for the instrument to do?”
In the end, it’s really simple. Do you like the sound of the pickup? Will it do the job that you’re looking for the instrument to do? When David Grissom worked with us on our DGT pickups, he spent almost a year on them, and at the end of the process, he was adjusting the coil wire by 25 turns at a time until it was exactly where he wanted it. And that’s only the amount of turns. We also evaluated the magnetic type, strength, etc. I bring up all these parameters to give you an idea of how complicated it is to get all the specifications to dance well together. I like what’s going on pickup-wise at PRS and believe that our 2025 offering is gonna turn some heads. Normally, I don’t bring up what we do at PRS in these articles, but this time I think it’s worth mentioning, so stay tuned.
Consider all the types of pickups out there: humbuckers, covered humbuckers, P-90s, Strat single-coils, Tele single-coils, Gretsch Filter’Trons, Jazzmaster, P Bass, Jazz Bass, no-hum single-coils, and mini-humbuckers that make single-coil sounds. Within each one of these types, there can be scores of variations. How to choose? Simply try a pickup and see if you like it!
Key Features of the ZOMA
● Intuitive Control Layout: Three large knobs give you full control over Reverb Level, Tremolo Rate,and Depth
● Easy Access to Alternate Controls: Adjust Reverb Decay, Reverb Tone, and Tremolo Volume withsimple alt-controls.
● Instant Effect Order Switching: Customize your signal path. Position tremolos after reverb for avintage, black-panel tone or place harmonic tremolo before reverb for a dirty, swampy sound.
● True Bypass or Buffered Trails: Choose the setting that best suits your rig.
Three Reverb and Tremolo Modes:
● SS – Spring Reverb & Sine Tremolo: Classic spring reverb paired with a sine wave tremolo for that timelessblack-panel amp tone.
● PH – Plate Reverb & Harmonic Tremolo: Smooth, bright plate reverb combined with swampy harmonictremolo.
● PV – Plate Reverb & Pitch Vibrato: Achieve a vocal-like vibrato with ethereal plate reverb.
Reverb: Sounds & Controls
● Spring Reverb: Authentic tube amp spring reverb that captures every detail of vintage sound.
● Plate Reverb: Bright and smooth, recreating the lush tones of vibrating metal plates.
● Reverb Decay: Adjust the decay time using the REVERB/ALT SWITCH while turning the Level knob.
● Reverb Tone: Modify the tone of your reverb using the REVERB/ALT SWITCH while turning the Rate knob.
Tremolo: Sounds & Controls
● Sine Wave/Volume Tremolo: Adjusts the volume of the signal up and down with smooth sine wavemodulation.
● Harmonic Tremolo: Replicates classic tube-amp harmonic tremolo, creating a phaser-like effect withphase-split filtering.
● Pitch Vibrato: Delivers pitch bending effects that let you control how far and how fast notes shift.
● Alt-Control Tremolo Boost Volume: Adjust the boost volume by holding the REVERB/ALT footswitch whileturning the Depth knob.
The ZOMA is built with artfully designed circuitry and housed in a proprietary angled aluminum enclosure, ensuring both simplicity and durability. Like all Keeley pedals, it’s proudly designed and manufactured in the USA.
ZOMA Stereo Reverb and Tremolo
The first sound effects built into amplifiers were tremolo and reverb. Keeley’s legendary reverbs are paired with their sultry, vocal-like tremolos to give you an unreal sonic experience.
Stevie Ray Vaughan was a force of nature. With his “Number One” Strat, he drove a veritable trove of amps—including vintage Fenders, a rotating Vibratone cab, and a Dumble—to create one of the most compelling tones of all, capable of buttery warmth, percussive pick articulation, and cathartic, screaming excess. As he drew upon an endless well of deeply informed blues guitar vocabulary, his creativity on the instrument seemingly knew no bounds.
Your 100 Guitarists hosts are too young to have experienced SRV live. We’ve spent decades with the records, live bootlegs, and videos, but we’ll never know quite how it felt to be in the room with SRV’s guitar sound. So, we’d like to spend some time imagining: How did it feel when it hit you? How did he command his band, Double Trouble? The audience?
SRV was mythical. His heavy-gauge strings tore up his fingers and made a generation of blues guitarists work a lot harder. And his wall of amps seems finely curated to push as much air in all directions as possible. How far did he take it? Was he fine-tuning his amps to extreme degrees? Or could he get his sound out of anything he plugged into?
