Add ethereal layers to your chord progressions by inserting a few carefully selected open strings.
Chops: Intermediate
Theory: Intermediate
Lesson Overview:
• Create introspective and dark phrases that include open strings.
• Imply extended harmonies by moving basic shapes up the neck.
• Learn how to cop some of Tosin Abasi's 8-string mojo. Click here to download a printable PDF of this lesson's notation.
One of the more exciting aspects of fretboard geometry is that it's possible to include wide intervallic leaps in licks and chords by using open strings. Open-string chords are extremely common in the progressive realm, as it makes it easier to add color to ordinary chords. You'll hear this regularly in the guitar playing of everyone from Alex Lifeson and John Petrucci to Misha Mansoor and Tosin Abasi.
If you're working in standard tuning, you have the notes E, A, D, G, and B that can be added to chord voicings. For example, play an A major triad at the 2nd fret on strings 3–1 (A–C#–E). Now replace the C# with the open 2nd string (B). Whoa—you've just created a jangly Asus2 (A–B–E), which sounds much more intriguing than a plain ol' A chord.
One of the quickest ways to get these chords under your belt is to take a simple chord voicing like an open E and move it up and down the neck while letting the top two strings (B and E, respectively) ring out. In Ex. 1,I take a simple grip on the lowest four strings and move it up and down the neck to create some interesting—and otherwise unplayable—sounds. Now, these chords aren't diatonic since they come from many different keys, but the open strings help to tie the progression together.
Click here for Ex. 1
We explore a similar principle in Ex. 2, starting with a B5 chord. We're still keeping the top two open strings while moving the bass note around. This example works so well because it's not just the open strings tying the chords together, but also the F# and B on the 4th and 3rd strings, respectively. The tension takes on a new flavor with the F#11 chord when the 3rd-string B shifts down a half-step to A#, the 3 of the chord. But we still have that open ringing B on the 2nd string, which yields a tangy minor second interval against the A#.
Click here for Ex. 2
Ex. 3 exploits a classic chord movement that takes an open C major shape and slides it up the neck two frets to create a Dadd11 chord. This is pleasing because the fretted notes change while the open notes remain static, resulting in sounds that are more complex than a regular D chord. The second two measures take fretted notes on the 4th, 3rd, and 1st strings and keeps the 2nd string open. Against an E bass note, these voicings create some colorful E minor flavors.
Click here for Ex. 3
We move over to the djent side of things with Ex. 4. This one takes influence from Periphery's Mark Holcomb. (If you're into this style, be sure to check out my Periphery lesson.) Here, we're using a series of chords with multiple open strings. I find chords like this easier to approach when I focus on the fretted notes and consider the open strings just a bit of harmonious “noise." Which, in technical prog music, isn't a bad thing at all.
Let's break down these voicings a bit. In the first measure we have a Dm11, which is simply a D minor dyad with the open 3rd and 1st strings (G and E) acting as the 11 and 9, respectively. Our next chord is basically a vanilla C major triad on strings 5–4–3, but with a pair of E notes ringing on the top strings. The Am11 voicing adds a nice cluster on top of an open 5th string. The final two chords are essentially the same voicing, just slid up the neck. Once we shift up to the 8th fret, the function of the open 4th and 1st strings shift from a 3 and #11 to a 13 and a 7. It's essential to have your guitar properly intonated to make sure the chords ring true.
Click here for Ex. 4
The basic chord progression for Ex. 5 comes from a layered section in my tune, “Fly Away." I wanted to create a nice texture over a chord progression while using open strings.
Click here for Ex. 5
The second guitar part from this piece is shown in Ex. 6. Located roughly at the 6th position, the passage maintains the pattern on the top three strings while moving the bass line around on the 4th string. Presenting these two parts as though they're one creates a rich harmonic backdrop to solo over.
Click here for Ex. 6
Ex. 7 expands on this idea and gives you a serious picking workout: Here we're playing a series of chords on strings 4–3–2 while leaving the open 1st string to ring out. As with previous examples, this common tone (or pedal) helps to connect chords that otherwise wouldn't work together.
Click here for Ex. 7
Our final riff, Ex. 8, is inspired by Animals as Leaders' Tosin Abasi. (Although, yes—we are two strings short of his 8-string electric.) There are some big chords that are based around E Lydian (E–F#–G#–A#–B–C#–D#) and use the 6th and 2nd strings for color. In essence, the chords played are essentially maj13 shapes with an open 2nd string, but because of the huge range, they sound extremely fresh. Tosin is a master of wide-range voicings, so it's well worth checking him out further for more exciting ideas.
Click here for Ex. 8
Obviously, we're merely scratching the surface of the possibilities here, and really the best thing to do is go out and learn as many prog songs as possible. When you find chords like these that appeal to you, make a note of them and then try weaving them into your own riffs and ideas.
Good luck, and I'll see you next month!
Day 6 of Stompboxtober is here! Today’s prize? A pedal from Revv Amplification! Enter now and check back tomorrow for the next one!
Revv G3 Purple Channel Preamp/Overdrive/Distortion Pedal - Anniversary Edition
The Revv G3 revolutionized high gain pedals in 2018 with its tube-like response & tight, clear high gain tones. Suddenly the same boutique tones used by metal artists & producers worldwide were available to anyone in a compact pedal. Now the G3 returns with a new V2 circuit revision that raises the bar again.
Beauty and sweet sonority elevate a simple-to-use, streamlined acoustic and vocal amplifier.
An EQ curve that trades accuracy for warmth. Easy-to-learn, simple-to-use controls. It’s pretty!
Still exhibits some classic acoustic-amplification problems, like brash, unforgiving midrange if you’re not careful.
$1,199
Taylor Circa 74
taylorguitars.com
Save for a few notable (usually expensive) exceptions, acoustic amplifiers are rarely beautiful in a way that matches the intrinsic loveliness of an acoustic flattop. I’ve certainly seen companies try—usually by using brown-colored vinyl to convey … earthiness? Don’t get me wrong, a lot of these amps sound great and even look okay. But the bar for aesthetics, in my admittedly snotty opinion, remains rather low. So, my hat’s off to Taylor for clearing that bar so decisively and with such style. The Circa 74 is, indeed, a pretty piece of work that’s forgiving to work with, ease to use, streamlined, and sharp.
Boxing Beyond Utility
Any discussion of trees or wood with Bob Taylor is a gas, and highly instructive. He loves the stuff and has dabbled before in amplifier designs that made wood an integral feature, rather than just trim. But the Circa 74 is more than just an aesthetic exercise. Because the Taylor gang started to think in a relatively unorthodox way about acoustic sound amplification—eschewing the notion that flat frequency response is the only path to attractive acoustic tone.
I completely get this. I kind of hate flat-response speakers. I hate nice monitors. We used to have a joke at a studio I frequented about a pair of monitors that often made us feel angry and agitated. Except that they really did. Flat sound can be flat-out exhausting and lame. What brings me happiness is listening to Lee “Scratch” Perry—loud—on a lazy Sunday on my secondhand ’70s Klipsch speakers. One kind of listening is like staring at a sun-dappled summer garden gone to riot with flowers. The other sometimes feels like a stale cheese sandwich delivered by robot.
The idea that live acoustic music—and all its best, earthy nuances—can be successfully communicated via a system that imparts its own color is naturally at odds with acoustic culture’s ethos of organic-ness, authenticity, and directness. But where does purity end and begin in an amplified acoustic signal? An undersaddle pickup isn’t made of wood. A PA with flat-response speakers didn’t grow in a forest. So why not build an amp with color—the kind of color that makes listening to music a pleasure and not a chore?
To some extent, that question became the design brief that drove the evolution of the Circa 74. Not coincidentally, the Circa 74 feels as effortless to use as a familiar old hi-fi. It has none of the little buttons for phase correction that make me anxious every time I see one. There’s two channels: one with an XLR/1/4" combo input, which serves as the vocal channel if you are a singer; another with a 1/4" input for your instrument. Each channel consists of just five controls—level, bass, middle, and treble EQ, and a reverb. An 11th chickenhead knob just beneath the jewel lamp governs the master output. That’s it, if you don’t include the Bluetooth pairing button and 1/8" jacks for auxiliary sound sources and headphones. Power, by the way, is rated at 150 watts. That pours forth through a 10" speaker.Pretty in Practice
I don’t want to get carried away with the experiential and aesthetic aspects of the Circa 74. It’s an amplifier with a job to do, after all. But I had fun setting it up—finding a visually harmonious place among a few old black-panel Fender amps and tweed cabinets, where it looked very much at home, and in many respects equally timeless.
Plugging in a vocal mic and getting a balance with my guitar happened in what felt like 60 seconds. Better still, the sound that came from the Circa 74, including an exceedingly croaky, flu-addled human voice, sounded natural and un-abrasive. The Circa 74 isn’t beyond needing an assist. Getting the most accurate picture of a J-45 with a dual-source pickup meant using both the treble and midrange in the lower third of their range. Anything brighter sounded brash. A darker, all-mahogany 00, however, preferred a scooped EQ profile with the treble well into the middle of its range. You still have to do the work of overcoming classic amplification problems like extra-present high mids and boxiness. But the fixes come fast, easily, and intuitively. The sound may not suggest listening to an audiophile copy of Abbey Road, as some discussions of the amp would lead you to expect. But there is a cohesiveness, particularly in the low midrange, that does give it the feel of something mixed, even produced, but still quite organic.
The Verdict
Taylor got one thing right: The aesthetic appeal of the Circa 74 has a way of compelling you to play and sing. Well, actually, they got a bunch of things right. The EQ is responsive and makes it easy to achieve a warm representation of your acoustic, no matter what its tone signature. It’s also genuinely attractive. It’s not perfectly accurate. Instead, it’s rich in low-mid resonance and responsive to treble-frequency tweaks—lending a glow not a million miles away from a soothing home stereo. I think that approach to acoustic amplification is as valid as the quest for transparency. I’m excited to see how that thinking evolves, and how Taylor responds to their discoveries.
The evolution of Electro-Harmonix’s very first effect yields a powerful boost and equalization machine at a rock-bottom price.
A handy and versatile preamp/booster that goes well beyond the average basic booster’s range. Powerful EQ section.
Can sound a little harsh at more extreme EQ ranges.
$129
Electro-Harmonix LPB-3
ehx.com
Descended from the first Electro-Harmonix pedal ever released, the LPB-1 Linear Power Booster, the new LPB-3 has come a long way from the simple, one-knob unit in a folded-metal enclosure that plugged straight into your amplifier. Now living in Electro-Harmonix’s compact Nano chassis, the LPB-3 Linear Power Booster and EQ boasts six control knobs, two switches, and more gain than ever before.
If 3 Were 6
With six times the controls found on the 1 and 2 versions (if you discount the original’s on/off slider switch,) the LPB-3’s control complement offers pre-gain, boost, mid freq, bass, treble, and mid knobs, with a center detent on the latter three so you can find the midpoint easily. A mini-toggle labeled “max” selects between 20 dB and 33 dB of maximum gain, and another labeled “Q” flips the resonance of the mid EQ between high and low. Obviously, this represents a significant expansion of the LPB’s capabilities.
More than just a booster with a passive tone, the LPB-3 boasts a genuine active EQ stage plus parametric midrange section, comprising the two knobs with shaded legends, mid freq and mid level. The gain stages have also been reimagined to include a pre-gain stage before the EQ, which enables up to 20 dB of input gain. The boost stage that follows the EQ is essentially a level control with gain to allow for up to 33 dB of gain through the LPB-3 when the “max” mini toggle is set to 33dB
A slider switch accessible inside the pedal selects between buffered or true bypass for the hard-latch footswitch. An AC adapter is included, which supplies 200mA of DC at 9.6 volts to the center-negative power input, and EHX specifies that nothing supplying less than 120mA or more than 12 volts should be used. There’s no space for an internal battery.
Power-Boosted
The LPB-3 reveals boatloads of range that betters many linear boosts on the market. There’s lots of tone-shaping power here. Uncolored boost is available when you want it, and the preamp gain knob colors and fattens your signal as you crank it up—even before you tap into the massive flexibility in the EQ stage.
“The preamp gain knob colors and fattens your signal as you crank it up—even before you tap into the massive flexibility in the EQ stage.”
I found the two mid controls work best when used judiciously, and my guitars and amps preferred subtle changes pretty close to the midpoint on each. However, there are still tremendous variations in your mid boost (or scoop, for that matter) within just 15 or 20 percent range in either direction from the center detent. Pushing the boost and pre-gain too far, particularly with the 33 dB setting engaged, can lead to some harsh sounds, but they are easy to avoid and might even be desirable for some users that like to work at more creative extremes.
The Verdict
The new LPB-3 has much, much more range than its predecessors, providing flexible preamp, boost, and overdrive sounds that can be reshaped in significant ways via the powerful EQ. It gives precise tone-tuning flexibility to sticklers that like to match a guitar and amp to a song in a very precise way, but also opens up more radical paths for experimentalists. That it does all this at a $129 price is beyond reasonable.
Electro-Harmonix Lpb-3 Linear Power Booster & Eq Effect Pedal Silver And Blue
Intermediate
Intermediate
• Learn classic turnarounds.
• Add depth and interest to common progressions.
• Stretch out harmonically with hip substitutions.
Get back to center in musical and ear-catching ways.
A turnaround chord progression has one mission: It allows the music to continue seamlessly back to the beginning of the form while reinforcing the key center in a musically interesting way. Consider the last four measures of a 12-bar blues in F, where the bare-bones harmony would be C7-Bb7-F7-F7 (one chord per measure). With no turn around in the last two measures, you would go back to the top of the form, landing on another F7. That’s a lot of F7, both at the end of the form, and then again in the first four bars of the blues. Without a turnaround, you run the risk of obscuring the form of the song. It would be like writing a novel without using paragraphs or punctuation.
The most common turnaround is the I-VI-ii-V chord progression, which can be applied to the end of the blues and is frequently used when playing jazz standards. Our first four turnarounds are based on this chord progression. Furthermore, by using substitutions and chord quality changes, you get more mileage out of the I-VI-ii-V without changing the basic functionality of the turnaround itself. The second group of four turnarounds features unique progressions that have been borrowed from songs or were created from a theoretical idea.
In each example, I added extensions and alterations to each chord and stayed away from the pure R-3-5-7 voicings. This will give each chord sequence more color and interesting voice leading. Each turnaround has a companion solo line that reflects the sound of the changes. Shell voicings (root, 3rd, 7th) are played underneath so that the line carries the sound of the written chord changes, making it easier to hear the sound of the extensions and alterations. All examples are in the key of C. Let’s hit it.
The first turnaround is the tried and true I-VI-ii-V progression, played as Cmaj7-A7-Dm7-G7. Ex. 1 begins with C6/9, to A7(#5), to Dm9, to G7(#5), and resolves to Cmaj7(#11). By using these extensions and alterations, I get a smoother, mostly chromatic melodic line at the top of the chord progression.
Ex. 2 shows one possible line that you can create. As for scale choices, I used C major pentatonic over C6/9, A whole tone for A7(#5), D Dorian for Dm9, G whole tone for G7(#5), and C Lydian for Cmaj7(#11) to get a more modern sound.
The next turnaround is the iii-VI-ii-V progression, played as Em7-A7-Dm7-G7 where the Em7 is substituted for Cmaj7. The more elaborate version in Ex. 3 shows Em9 to A7(#9)/C#, to Dm6/9, to G9/B, resolving to Cmaj7(add6). A common way to substitute chords is to use the diatonic chord that is a 3rd above the written chord. So, to sub out the I chord (Cmaj7) you would use the iii chord (Em7). By spelling Cmaj7 = C-E-G-B and Em7 = E-G-B-D, you can see that these two chords have three notes in common, and will sound similar over the fundamental bass note, C. The dominant 7ths are in first inversion, but serve the same function while having a more interesting bass line.
The line in Ex. 4 uses E Dorian over Em9, A half-whole diminished over A7(#9)/C#, D Dorian over Dm6/9, G Mixolydian over G9/B, and C major pentatonic over Cmaj7(add6). The chord qualities we deal with most are major 7, dominant 7, and minor 7. A quality change is just that… changing the quality of the written chord to another one. You could take a major 7 and change it to a dominant 7, or even a minor 7. Hence the III-VI-II-V turnaround, where the III and the VI have both been changed to a dominant 7, and the basic changes would be E7-A7-D7-G7.
See Ex. 5, where E7(b9) moves to A7(#11), to D7(#9) to G7(#5) to Cmaj9. My scale choices for the line in Ex. 6 are E half-whole diminished over E7(#9), A Lydian Dominant for A7(#11), D half-whole diminished for D7(#9), G whole tone for G7(#5), and C Ionian for Cmaj9.
Ex. 7 is last example in the I-VI-ii-V category. Here, the VI and V are replaced with their tritone substitutes. Specifically, A7 is replaced with Eb7, and G7 is replaced with Db7, and the basic progression becomes Cmaj7-Eb7-Dm7-Db7. Instead of altering the tritone subs, I used a suspended 4th sound that helped to achieve a diatonic, step-wise melody in the top voice of the chord progression.
The usual scales can be found an Ex. 8, where are use a C major pentatonic over C6/9, Eb Mixolydian over Eb7sus4, D Dorian over Dm11, Db Mixolydian over Db7sus4, and once again, C Lydian over Cmaj7(#11). You might notice that the shapes created by the two Mixolydian modes look eerily similar to minor pentatonic shapes. That is by design, since a Bb minor pentatonic contains the notes of an Eb7sus4 chord. Similarly, you would use an Ab minor pentatonic for Db7sus4.
The next four turnarounds are not based on the I-VI-ii-V chord progression, but have been adapted from other songs or theoretical ideas. Ex. 9 is called the “Backdoor” turnaround, and uses a iv-bVII-I chord progression, played as Fm7-Bb7-Cmaj7. In order to keep the two-bar phrase intact, a full measure of C precedes the actual turnaround. I was able to compose a descending whole-step melodic line in the top voice by using Cmaj13 and Cadd9/E in the first bar, Fm6 and Ab/Bb in the second bar, and then resolving to G/C. The slash chords have a more open sound, and are being used as substitutes for the original changes. They have the same function, and they share notes with their full 7th chord counterparts.
Creating the line in Ex. 10 is no more complicated than the other examples since the function of the chords determines which mode or scale to use. The first measure employs the C Ionian mode over the two Cmaj chord sounds. F Dorian is used over Fm6 in bar two. Since Ab/Bb is a substitute for Bb7, I used Bb Mixolydian. In the last measure, C Ionian is used over the top of G/C.
The progression in Ex. 11 is the called the “Lady Bird” turnaround because it is lifted verbatim from the Tadd Dameron song of the same name. It is a I-bIII-bVI-bII chord progression usually played as Cmaj7-Eb7-Abmaj7-Db7. Depending on the recording or the book that you check out, there are slight variations in the last chord but Db7 seems to be the most used. Dressing up this progression, I started with a different G/C voicing, to Eb9(#11), to Eb/Ab (subbing for Abmaj7), to Db9(#11), resolving to C(add#11). In this example, the slash chords are functioning as major seventh chords.
As a result, my scale choices for the line in Ex. 12 are C Ionian over G/C, Eb Lydian Dominant over Eb9(#11), Ab Ionian over Eb/Ab, Db Lydian Dominant over Db9(#11), and C Lydian over C(add#11).
The progression in Ex. 13 is called an “equal interval” turnaround, where the interval between the chords is the same in each measure. Here, the interval is a descending major 3rd that creates a I-bVI-IV-bII sequence, played as Cmaj7-Abmaj7-Fmaj7-Dbmaj7, and will resolve a half-step down to Cmaj7 at the top of the form. Since the interval structure and chord type is the same in both measures, it’s easy to plane sets of voicings up or down the neck. I chose to plane up the neck by using G/C to Abmaj13, then C/F to Dbmaj13, resolving on Cmaj7/E.
The line in Ex. 14 was composed by using the notes of the triad for the slash chord and the Lydian mode for the maj13 chords. For G/C, the notes of the G triad (G-B-D) were used to get an angular line that moves to Ab Lydian over Abmaj13. In the next measure, C/F is represented by the notes of the C triad (C-E-G) along with the root note, F. Db Lydian was used over Dbmaj13, finally resolving to C Ionian over Cmaj7/E. Since this chord progression is not considered “functional” and all the chord sounds are essentially the same, you could use Lydian over each chord as a way to tie the sound of the line together. So, use C Lydian, Ab Lydian, F Lydian, Db Lydian, resolving back to C Lydian.
The last example is the “Radiohead” turnaround since it is based off the chord progression from their song “Creep.” This would be a I-III-IV-iv progression, and played Cmaj7-E7-Fmaj7-Fm7. Dressing this one up, I use a couple of voicings that had an hourglass shape, where close intervals were in the middle of the stack.
In Ex. 15 C6/9 moves to E7(#5), then to Fmaj13, to Fm6 and resolving to G/C. Another potential name for the Fmaj13 would be Fmaj7(add6) since the note D is within the first octave. This chord would function the same way, regardless of which name you used.
Soloing over this progression in Ex. 16, I used the C major pentatonic over C6/9, E whole tone over E7(#5), F Lydian over Fmaj13, and F Dorian over Fm6. Again, for G/C, the notes of the G triad were used with the note E, the 3rd of a Cmaj7 chord.
The main thing to remember about the I-VI-ii-V turnaround is that it is very adaptable. If you learn how to use extensions and alterations, chord substitutions, and quality changes, you can create some fairly unique chord progressions. It may seem like there are many different turnarounds, but they’re really just an adaptation of the basic I-VI-ii-V progression.
Regarding other types of turnarounds, see if you can steal a short chord progression from a pop tune and make it work. Or, experiment with other types of intervals that would move the chord changes further apart, or even closer together. Could you create a turnaround that uses all minor seventh chords? There are plenty of crazy ideas out there to work with, and if it sounds good to you, use it!
