Steve Stevens Rig Rundown

There’s nothing subtle about Billy Idol, so it tracks that there’d be nothing subtle about the guitars used onstage by his longtime guitarist, Steve Stevens. Famous for his guitar work with Idol and the Grammy-winning symphony of sustain “Top Gun Anthem,” Stevens brought a brigade of eye-popping signature electrics and some choice other jewels out on the road with Idol this spring.

The tour touched down at Bridgestone Arena in downtown Nashville in May, and while Stevens was jetting into town, PG’s John Bohlinger met up with tech and guitar builder Frank Falbo to learn the ins and outs of Stevens’ rig.

Brought to you by D’Addario

Cherry Pie

This cherryburst is one of a score of single-cut Knaggs Steve Stevens signature models in Stevens’ arsenal. He plays with heavier Tortex picks and uses Ernie Ball strings, usually .010–.048s.

More, More, More (Sustain)

This Knaggs Steve Stevens Severn XF, complete with a Sustainiac pickup system, was designed to mimic the look of one of his old guitars, and the stage lights make this finish go insane. It comes out for three to four songs in any given set, including “Rebel Yell.”

Songs from the Sparkle Lounge

This Knaggs Steve Stevens, finished in silver sparkle, is outfitted with a killswitch, push-pull control knobs, and Fishman Fluence pickups. Falbo was on the R&D team that helped design the Fluences.

Other guitars backstage include a red sparkle Knaggs with PAFs, a Godin LGXT with piezo saddles and Seymour Duncan pickups that sends three signals (synth, electric, and piezo), a pair of piezo- and MIDI-equipped Godin nylon-string guitars, a dazzling Gibson Les Paul with stock Gibson pickups, a Suhr T-style electric, and a Ciari Ascender for travel and dressing-room rehearsal.

Tube Heart, Digital Brains

Stevens runs through a pair of Friedman heads—a B100 and Steve Stevens SS100, plus a third backup—with each panned hard to either the left or right. Both signals run through a Neve 8803 rack EQ into two RedSeven Amplification Amp Central Evo loadboxes, and through their impulse response programs to front of house. A Neural Quad Cortex is on hand as a backup and for fly dates.

Steve Stevens’ Pedalboard

Stevens’ pedal playground is masterminded by an RJM Mastermind GT, which lives on its own board alongside a Fractal FM3 MK II. He orchestrates most of the changes himself, but Falbo is ready to flip switches backstage in case Stevens is away from his board for a key moment.

The centre hub, built on a Tone Merchants board, carries a TC Electronic PolyTune2 Noir, Xotic Effects Super Sweet Booster, Vox wah, Ernie Ball volume pedal, Mission Engineering expression pedal, DigiTech Whammy Ricochet, Suhr Discovery, JHS Muffuletta, DigiTech Drop, ISP DECI-MATE, Walrus Voyager, Suhr Koji Comp, Zvex Super Ringtone, DryBell Vibe Machine, and Ammoon EX EQ7. An Ebtech Hum Eliminator, two Strymon Ojais, and a Strymon Zuma keep the wheels greased.

The board to the right carries a Boss RV-500, Fender Smolder Acoustic OD, Lehle Dual Expression, Boss GM-800, Empress Bass Compressor, Grace Design ALiX preamp, Fishman Aura, and a Peterson tuner. Utility boxes include an Ernie Ball Volt and a Radial J48.

TC Electronic PolyTune3 Noir

Vox Wah

Ernie Ball Volume Pedal

Mission Engineering Expression Pedal

DigiTech Whammy Ricochet

Suhr Discovery

JHS Muffuleta

DigiTech Drop

ISP DECI-MATE

Walrus Audio Voyager

Suhr Koji Comp

Strymon Ojais

Strymon Zuma

Boss RV-500

Fender Smolder Acoustic OD

Lehle Dual Expression

Boss GM-800

Empress Bass Compressor

Grace Design ALiX preamp

Fishman Aura

Peterson Tuner

Ernie Ball Volt

Radial J48

Friedman B100 and Steve Stevens SS100

Neve 8803

Tortex Picks

Ernie Ball Strings

Fishman Fluence Pickups

Godin LGXT

Seymour Duncan Pickups

Gibson Les Paul

Suhr T-style
