The Jack White Pano Verb features unique stereo-imagine options. “[White] wanted to be able to do sort of startling things with each speaker’s content,” says Fender’s Stan Cotey.
This week, Fender and Jack White dropped a new line that spun heads across the guitar-gear universe, proving that the Third Man’s brain knows no bounds. White has been blowing minds with Third Man Hardware’s line of collaboratively conceived gear. Working with makers of all sizes, each yellow-and-black piece is as unique as White himself.
Hooking up with Fender for the Jack White Signature Collection—which includes the Signature model hot-rod Jack White TripleCaster Telecaster and the stunning Jack White TripleSonic Acoustasonic—is as big as it gets, and this week’s announcement is proportionately epic.
The all-new Jack White Pano Verb amp looks to be one of the most forward-thinking advances in tube amps we’ve seen in … well, a very long time! Although it’s roughly inspired by three vintage Fender models—a 1964 Vibroverb, a 1960 Vibrasonic, and a 1993 Vibro-King—the Pano Verb is a rare all-new design that is poised to thrill. The single-channel stereo amp delivers 70 watts of combined power and features stereo harmonic tremolo and stereo reverb circuits, with unique routing options through the hip pair of 15" and 10" speakers. If you haven’t checked out Fender’s video announcing the amp, prepare to have your mind blown by the possibilities.
“It wasn’t based on what we could or couldn’t do, or what even was or wasn’t possible. It was just what Jack was looking to accomplish.”
Fender Vice President of Research and Development Stan Cotey, who worked closely with White to develop the prototypes for the Pano Verb, says, “There were no restrictions as far as how wild something could be. It wasn’t based on what we could or couldn’t do or what even was or wasn’t possible. It was just what Jack was looking to accomplish.” Putting those goals into action was a kick for Cotey. “I love the fact that we’re still pushing the idea of vacuum tubes and that there are things remaining to be done,” he says. “And [the Pano Verb] is a really crazy thing. It’s fun when one of the larger companies tackles a big crazy thing and releases it in a bold manner.”
We rang up Cotey to get the scoop on designing the amp as we wait to get our hands on one.
Cotey calls the Pano Verb “a really crazy thing,” and says, “It’s fun when one of the larger companies tackles a big crazy thing and releases it in a bold manner.”
The Pano Verb has a refreshingly unique and adventurous set of features.
Stan Cotey: There’s two separate power amps, there’s two separate preamps, there’s a reverb circuit. There are two separate harmonic vibrato circuits. There’s two full, separate amps in it—there’s one power supply, but everything else, there’s at least two of.
There are several different kinds of stereo interaction that could happen. The harmonic vibrato could be stereo. The reverb, even though it’s a mono tank, could be steered to the speakers differently, which kind of gives a stereo-imaging thing. So, that opens up myriad possibilities for how things could work.
How involved was Jack in the design?
Cotey: He was completely hardcore. He cared in great detail, exactly down to fine decimal points, how it worked. He was very particular about the voicing. He was very particular about the features he knew. He’s pretty studio savvy, so he had a sense of routing, how he wanted the stereo interaction of the sections to work together. He very much had an idea of stereo-ness for the amp at the outset of it. He talked early on about miking both speakers and panning them—he wanted to be able to do sort of startling things with each speaker’s content.
I think my role was to take the stuff that he wanted to do and figure out how we could do it. So, the stereo-ness of the amp, the 10" speaker versus the 15" speaker, the routing stuff you could do where the reverb goes to one speaker or both, all that stuff came from Jack.
Jack’s Vibrasonic was a touchstone for the Pano Verb.
Cotey: That amp lived with me for quite a while. He knew that he liked the harmonic tremolo.
The stereo harmonic tremolo, that’s a fairly part-intensive circuit, even in a normal brown amp. In this amp, there’s two full circuits in it, so it is literally double the parts of one of the more complicated earlier ’60s amps, just for that part of the amp. I worked out how that works. That’s two harmonic tremolos that are in sync, but opposite polarity. So, when one’s going up, the other is going down, and vice versa.
Stan Cotey is Fender’s Vice President of Guitar Research and Development and worked with White to design the prototypes for the Pano Verb.
The reverb mix on the Pano Verb is rooted in some vintage designs, but it’s handled a little differently here.
Cotey: In the video, he talked about the reverb tank in front of the amp, which forms the Vibro-King, and that he liked the idea. I think he liked the idea of having a more comprehensive, dedicated reverb circuit in an amp, not where it’s just kind of spread on the top, like margarine or something.
In a traditional Fender amp, there’s a feed that comes off the preamp circuit that goes to a driver, which is a tube and a little transformer, and that drives the reverb tank. Then, the output of the reverb tank goes into a recovery amp, a little gain stage with a tube, and that gets mixed with the output of the channel and shoved into the power amp. So, the reverb kind of occurs between the preamp and the power amp. It largely takes the tonality of the preamp on because the tone controls are upstream of it.
Jack has an old Fender amp from the early ’60s that had reverb added. I don’t know who modified it, but they actually used the second channel of the amp as the reverb return, which I think is really super clever. Then you get tone controls for the reverb. So that’s where that idea came from. He didn’t necessarily want the reverb circuit in front. He liked it between the preamp and the power amp, but he wanted to have it be more comprehensive than what would be on a typical mid-’60s Fender amplifier.
What was the most exciting feature for you to create?
The stereo harmonic tremolo was really fun, and the journey that we went on to get there was really cool. I have a tweed amp from the late ’50s from Guild that has tremolo in it, and it’s a stereo amp. It has two separate everythings. The tremolo only works on one side, and that gives the apparent sound that it’s kind of going back and forth between the speakers. We tried having just the harmonic tremolo on one side of this, and it really wanted to have two complete full circuits. So that was one of the changes that got made.
Getting the power amps to work well together was fun too. That was more about transformer and tube selection and working the power supply parts out, getting the amps where they would distort in the right way at the right times or right level. But the harmonic tremolo was definitely the elephant dancing on the bucket with the streamers going off.
- Ear to the Ground: Jack White's "High Ball Stepper" ›
- Third Man Hardware and MXR Release the Double Down ›
- The Raconteurs’ Jack White and Brendan Benson ›
- John Bohlinger Explores Jack White's Fender Pano Verb Amps - Premier Guitar ›
- Jack White Rig Rundown: Tone Wizard's 2024 Tour Gear - Premier Guitar ›
This month’s mod Dan’s uses a 500k linear pot, a 1.5H inductor (L) with a 0.039 µF (39nF) cap (C), and a 220k resistor (R) in parallel.
Don’t let the name fool you, this is a purely passive device—nothing is going to be boosted. In general, you can’t increase anything with passive electronics that isn’t already there. Period. But you can reshape the tone by deemphasizing certain frequencies and making others more prominent (so … “boost” in guitar marketing language). Removing highs makes lows more apparent, and vice versa. In addition, the use of inductors (which create the magnetic field in a guitar circuit) and capacitors will create resonant peaks and valleys (bandpasses and notches), further coloring the overall tone. This type of bandpass filter only allows certain frequencies to pass through, while others are blocked, and it all works at unity gain.
“You can’t increase anything with passive electronics that isn’t already there … but you can reshape the tone by deemphasizing certain frequencies and making others more prominent.”
All the systems I mentioned above are doing more or less the same thing, using different approaches and slightly different component values. They are all meant to be updated tone controls. Our common tone circuit is usually a variable low-pass filter (aka treble-cut filter), which only allows the low frequencies to pass through, while the high frequencies get sent to ground via the tone cap. Most of these systems are LCR networks, which means that there is not only a capacitor (C), like on our standard tone controls, but also an inductor (L) and a resistor (R).
In general, all these systems are meant to control the midrange in order to scoop the mids, creating a mid-cut. This can be a cool sounding option, e.g. on a Strat for that mid-scooped neck and middle tone.
Dan Torres offered his “midrange kit” via an internet shop that is no longer online, same with his business website. The Torres design is a typical LCR network and looks like the illustration at the top of this column.
Dan’s design uses a 500k linear pot, a 1.5H inductor (L) with a 0.039 µF (39nF) cap (C), and a 220k resistor (R) in parallel. Let’s break down the parts piece by piece:
Any 500k linear pot will do the trick, in one of the rare scenarios where a linear pot works better in a passive guitar system than an audio pot.
(C) 0.039µF cap: This is kind of an odd value. Keeping production tolerances of up to 20 percent in mind, any value that is close will do, so you can use any small cap you want for this. I would prefer a small metallized film cap, and any voltage rating will do. If you want to stay as close as possible to the original design, use any 0.039 µF low-tolerance film cap.
(L) 1.5H inductor: The original design uses a Xicon 42TL021 inductor, which is easy to find and fairly priced. This one is also used in the Bill Lawrence Q-Filter design, the Gibson standard Varitone, and many other systems like this. It’s very small, so it will fit in virtually every electronic compartment of a guitar. It has a frequency range of 300 Hz up to 3.4 kHz, with a primary impedance of 4k ohms (that’s the one we want to use) and a secondary impedance of 600 ohms. Snip off the three secondary leads and the center tap of the primary side and use the two remaining outer primary leads; the primary side is marked with a “P.” On the pic, you can see the two leads you need marked in red, all other leads can be snipped off. You can connect the two remaining leads to the pot either way; it doesn’t matter which of them is going to ground when using it this way.
Drawing courtesy of singlecoil.com
(R) 220k: use a small axial metal film resistor (0.25 W), which is easy to find and is the quasi-standard.
Other designs use slightly different part values—the Bill Lawrence Q-filter has a 1.8H L, 0.02 µF C and 8k R, while the old RA Gresco Tone Qube from the ’80s has a 1.5H L, 0.0033 µF C, and a 180k R, so this is a wide field for experimentation to tweak it for your personal tone.
This mid-cut system can be put into any electric guitar not only as a master tone, but also together with a regular tone control or something like the Fender Greasebucket, or it can be assigned only to a certain pickup. It can be a great way to enhance your sonic palette, so give it a try.
That’s it! Next month, we’ll take a deeper look into how to fight feedback on a Telecaster. It’s a common issue, so stay tuned!
Until then ... keep on modding!
