Take off the training wheels and burn through these pentatonic licks.
Advanced
Intermediate
• Develop a deeper sense of subdivisions.
• Understand how to use alternate pentatonic scales.
• Learn how to balance different picking styles.
Pentatonics are certainly well used (maybe overused?) by guitarists. There’s so much you can do with them and there’s a lot of great music to be found within our beloved five-note scale. My aim is to go for the whole “sheets of sound” thing that was popularized by John Coltrane and later adapted to guitar by players like Allan Holdsworth. However, the technique arms race has slowed down over the last few years, with modern players opting for interesting lines that focus more on cool rhythms and unexpected intervals. Let’s get to it.
My reference for this style is players like Plini, Rick Graham, and Jack Gardiner, and these kinds of lines can be heard on their albums and in their improvisations. My hope is to introduce different technical, rhythmic, and textural ways of approaching the well-worn minor pentatonic scale.
Plini – "FLÂNEUR" (Live 2019)
Ex. 1 isn’t really a lick, but it’s a way of combining positions of the A minor pentatonic scale (A–C–D–E–G). We start out with two notes on the 6th string, then three on the 5th, one on the 4th, three on the 3rd, one on the 2nd, and two on the 1st string. This is very similar to some of the picking patterns found in Frank Gambale’s playing. Visualizing the scale this way will open up all kinds of phrasing and technique options. I’ll be using patterns like this throughout this column as my foundation for building the lines.
Ex. 1
You knew we were going to hit legato at some point. Three-note-per-string patterns work great for legato playing. In Ex. 2, I’m playing patterns of seven on each string, starting on the lowest note of each three, rolling up and down to create a pattern of seven notes. I’m aiming to get this as close to a septuplet as possible. It can also be helpful to practice these patterns as straight 16th-notes, as I demonstrate in the second part of this example.
Ex. 2
Ex. 3 uses a similar approach to Ex. 2, however this time we’re employing string skipping. Now we’re getting those sheets of sound I was talking about. I start out with groups of seven, then I go for a more linear approach with straight up-and-down string skipping. I follow this as straight 16th-notes to practice balancing the evenness between the hammer-ons and pull-offs. You’re welcome to execute this line however you wish, with picking, hammers from nowhere, or various tapping approaches.
Ex. 3
Let’s move to the E minor pentatonic scale (E–G–A–B–D) for Ex. 4. Playing a minor pentatonic scale based a fifth above the root offers some interesting melodies. In the key of A minor the E minor pentatonic scale gives us the 5, b7, root, 9, and 11. Super imposing pentatonics gives our classic phrases a totally different feel. Another thing unique about this phrase is that we’re using a 2-1-2 pattern, where we play two notes on one string, one note on an adjacent string, and then two notes on next adjacent string. It’s a superb way of getting modern-sounding interval phrases happening across the fretboard in lots of different situations. (For more on this check out my 2-1-2 lesson here.)
Ex. 4
Quintuplets (groups of 5) are a great way to break up the pentatonic scale. (Joe Bonamassa and Eric Johnson use this technique all the time.) For Ex. 5, we’re sticking with the E minor pentatonic 2-1-2 thing and moving across the strings before descending with a similar pattern in 12th position. The second half of the lick uses quintuplet quarter-notes (five notes over two beats) to create a deeper level of rhythmic interest.
Ex. 5
In Ex. 6 I add a note to our E minor pentatonic patterns to create a 3-1-2 pattern. This is great for modern sextuplet licks.
Ex. 6
Quite a lot of what I’ve covered in this column has been combination picking and legato. So, we might as well cover sweep picking as well. Ex. 7 is a sweep- or economy-picking lick, which means when you change strings your pick is going in the direction of the next string. If you’re new to it, try the second half of the lick first. Practice each fragment slowly first of all with even subdivisions, and ensure your pick is planted on the next string you’re moving to. Timing is everything!
Ex. 7
And there we have it, some mega pentatonic ideas to hopefully inspire new phrases in your playing. Pentatonic scales are super valuable and it’s worth finding as many ways of playing them as you can. Plus, the guitar has great geometric patterns we can make a lot of music from. The patterns in the 3-1-3 and 2-1-2 systems can be a bit tricky, so find the ones that resonate with you and don’t forget to mess with the super impositions and subdivisions for extra fun!
- Beyond Blues: The Mixo-Pentatonic Scale - Premier Guitar ›
- Beyond Blues: Moving Past the Pentatonic Scale - Premier Guitar ›
- Fretboard Workshop: Revisualize the Pentatonic Scale - Premier ... ›
We’re giving away more gear! Enter Stompboxtober Day 24 for your chance to win today’s pedal from Maxon!
Maxon OD-9 Overdrive Pedal
The Maxon OD-9 Overdrive Effects Pedal may look like your old favorite but that's where the similarity ends. Improved circuitry with a new chip yields the ultra-smooth dynamic overdrive guitarists crave. Drive and Level controls tweak the intensity and volume while the Hi-Boost/Hi-Cut tone controls adjust brightness. Features true bypass switching, a die-cast zinc case, and 3-year warranty. From subtle cries to shattering screams, the Maxon OD-9 delivers a huge range of tones.
Features
Improved circuitry with a new chip yields ultra-smooth dynamic overdrive
Drive and Level controls tweak the intensity and volume
Hi Boost/Hi Cut tone controls adjust brightness
True bypass switching
Die-cast zinc case
AC/DC operation (order optional Maxon AC210N adapter)
Product Specs
Input: 1/4" mono jack
Output: 1/4" mono jack
Power: 9V DC, 6 mA, center pin minus (not included)
Dimensions: (WxDxH) 74 mm x 124 mm x 54 mm
Weight: 580g
Pickups are more than magnets and coils. When you’re thinking about how they sound, consider all of the many elements that go into creating their tone.
Pickups, by definition, are magnetic microphones that lay under guitar strings. These devices are a fundamental piece of our musical instrument industry and, rightfully, get a lot of serious attention from guitarists/musicians. PRS has spent an inordinate amount of time, research, and engineering on these devices. They are complicated equations—a combination of magnetic materials, magnetic manufacturing/engineering methods, magnetic strength, physical dimensions and layout, coil winding for turning magnetic fields into electrical signals, coil-wire gauge and wire coating (type and thickness), wax potting to prevent howling and squealing (wax type and amount), electrostatic and magnetic hum protection in the form of pickup covers and cover material, cabling for attaching the pickup to the electronic controls of the instrument, pot values, and capacitor values and types.
The magic is in the interactive nature of all these factors … and then some. (This list is for passive pickups and does not include many aspects of active pickups.) Sometimes I see pickups boiled down to only a few factors, and I do not think that is a sophisticated enough view of these complicated and potentially beautiful-sounding devices.
As an example, it is thought that most players have an idea of the sound that humbucking pickups with alnico 4 magnets that are wound to 7.8k make. They’re historically associated with PAF humbuckers, but those qualities don’t fully explain what gives those pickups character. For example, if the pickup’s wire is standard-size 42 gauge, at 5,000 turns the pickup would have a resistance of about 7.5k. If you use 42-gauge wire that is undersized (which is a common inconsistency) and 4,800 turns, the pickup would still be around 7.5k. Because of the wire diameter and different number of turns, the pickups would sound different even though it’s the same magnet and same resistance. The wire matters; 7.5k is just the resistance of both coils. Just as wire diameter varies, alnico 4 purchased from four manufacturers sounds four different ways, so you have to compensate for that in other design areas as well.
If you think about the sound of a Strat, there is a “whistle note” (or you can think of it as a “ping note”) in every note you play. Think about playing on the neck pickup on a Strat; you can hear that whistle sound in every note. The pickup without a load is resonating at about 11k and at about 15 dB. Fifteen decibels is a lot. Imagine adding 15 dB of 11k (high treble) to your vocal at a gig! The potentiometers on a Strat, and those are 250k (which is a fairly low value for a volume and tone control), calm down how loud the whistle note is. When these single-coil pickups are built well, this whistle note can be very musical. Just think of Robbie Blunt playing “Big Log” on Robert Plant’s 1983 album The Principle of Moments. For us at PRS, getting the whistle note to be the right frequency and the right volume is very important. It is believed, for good reason, that an old PAF pickup can sound very much like a single-coil Strat pickup. That is because of the frequency and volume of the whistle note coming out of these vintage pickups.
“In the end, it’s really simple. Do you like the sound of the pickup? Will it do the job that you’re looking for the instrument to do?”
In the end, it’s really simple. Do you like the sound of the pickup? Will it do the job that you’re looking for the instrument to do? When David Grissom worked with us on our DGT pickups, he spent almost a year on them, and at the end of the process, he was adjusting the coil wire by 25 turns at a time until it was exactly where he wanted it. And that’s only the amount of turns. We also evaluated the magnetic type, strength, etc. I bring up all these parameters to give you an idea of how complicated it is to get all the specifications to dance well together. I like what’s going on pickup-wise at PRS and believe that our 2025 offering is gonna turn some heads. Normally, I don’t bring up what we do at PRS in these articles, but this time I think it’s worth mentioning, so stay tuned.
Consider all the types of pickups out there: humbuckers, covered humbuckers, P-90s, Strat single-coils, Tele single-coils, Gretsch Filter’Trons, Jazzmaster, P Bass, Jazz Bass, no-hum single-coils, and mini-humbuckers that make single-coil sounds. Within each one of these types, there can be scores of variations. How to choose? Simply try a pickup and see if you like it!
The Keeley ZOMA combines two of iconic amp effects—tremolo and reverb—into one pedal.
Key Features of the ZOMA
● Intuitive Control Layout: Three large knobs give you full control over Reverb Level, Tremolo Rate,and Depth
● Easy Access to Alternate Controls: Adjust Reverb Decay, Reverb Tone, and Tremolo Volume withsimple alt-controls.
● Instant Effect Order Switching: Customize your signal path. Position tremolos after reverb for avintage, black-panel tone or place harmonic tremolo before reverb for a dirty, swampy sound.
● True Bypass or Buffered Trails: Choose the setting that best suits your rig.
Three Reverb and Tremolo Modes:
● SS – Spring Reverb & Sine Tremolo: Classic spring reverb paired with a sine wave tremolo for that timelessblack-panel amp tone.
● PH – Plate Reverb & Harmonic Tremolo: Smooth, bright plate reverb combined with swampy harmonictremolo.
● PV – Plate Reverb & Pitch Vibrato: Achieve a vocal-like vibrato with ethereal plate reverb.
Reverb: Sounds & Controls
● Spring Reverb: Authentic tube amp spring reverb that captures every detail of vintage sound.
● Plate Reverb: Bright and smooth, recreating the lush tones of vibrating metal plates.
● Reverb Decay: Adjust the decay time using the REVERB/ALT SWITCH while turning the Level knob.
● Reverb Tone: Modify the tone of your reverb using the REVERB/ALT SWITCH while turning the Rate knob.
Tremolo: Sounds & Controls
● Sine Wave/Volume Tremolo: Adjusts the volume of the signal up and down with smooth sine wavemodulation.
● Harmonic Tremolo: Replicates classic tube-amp harmonic tremolo, creating a phaser-like effect withphase-split filtering.
● Pitch Vibrato: Delivers pitch bending effects that let you control how far and how fast notes shift.
● Alt-Control Tremolo Boost Volume: Adjust the boost volume by holding the REVERB/ALT footswitch whileturning the Depth knob.
The ZOMA is built with artfully designed circuitry and housed in a proprietary angled aluminum enclosure, ensuring both simplicity and durability. Like all Keeley pedals, it’s proudly designed and manufactured in the USA.
ZOMA Stereo Reverb and Tremolo
The first sound effects built into amplifiers were tremolo and reverb. Keeley’s legendary reverbs are paired with their sultry, vocal-like tremolos to give you an unreal sonic experience.
A Telefunken ELA M 251E large-diaphragm condenser mic, seen in its natural habitat.
By now, we’re all familiar with the many options out there for amp modeling. Mic modelers are another reliable asset to digital recording tech, and can rapidly grow your inventory with just a few clicks.
As guitarists, we’re very aware of amp-modeling and profiling technologies, such as the Line 6 Helix, Fractal Axe-Fx, Neural DSP Quad Cortex, and Kemper Profiler. While our bases are covered for these (with modelers available for every “holy grail” amp under the sun), we are still missing another vital area of the recording process—microphones—for the acoustic instruments and vocals we might want to capture.
What if we could record them using holy-grail-modeled microphones? This month, let’s evaluate microphone modeling to help you make better-sounding recordings. Tighten up, the Dojo is now open.
The Sincerest Form of Flattery
Microphone modeling is an intriguing advancement in recording technology, offering great flexibility and possibilities for musicians, producers, and engineers. Makers like Slate Digital, Antelope, and Antares make many offerings, from hardware to software.
Universal Audio’s Sphere DLX ($1299 Street), LX ($799), and their six new Standard Mic series have impeccably modeled classic mics, and when coupled with their classic mic pre and compressor plugins, you can enjoy the same highly coveted mic chains appreciated the world over.
How It Works
The technology behind microphone-modeling systems relies heavily on convolution and impulse response techniques. These techniques involve capturing the unique sonic fingerprint of a microphone by recording its response to a wide range of frequencies and sound pressure levels. The immediate benefit is that this means you can grow your mic locker exponentially and gain access to a wide range of legendary microphone tones and textures all from a single mic! Most modeling microphones are usually either small- or large-diaphragm, multi-pattern, condenser microphones that are capable of capturing a wide frequency range and dynamic response. By adding other modeling mics, you can record in stereo or surround, and/or record multiple instruments at a fraction of the cost of owning multiples of the modeled mics themselves.
A Wealth of Options
One significant advantage of mic-modeling systems is their ability to offer a vast array of microphone options within a single session instead of having the time-consuming duty of swapping them out to achieve different sounds. With a modeling system, you can switch between different mic models instantly and audition various mics to find the perfect tone for the recording.
“The same vintage microphone can sound different on different days depending on temperature, humidity, and the voltage from the wall.”
Another lovely bonus is that microphone-modeling systems also offer the ability to swap microphone characteristics after the recording has been made! Want to swap your AKG C12 for a Neumann U 47 long after the recording session is over? No problem! This is especially useful when the initial microphone choice may not have been ideal or when the production requires a different tonal character than originally intended.
Weighing the Pros and Cons
Some audio purists argue digital emulation can’t truly replicate the sound of a physical microphone, especially when it comes to vintage models that have unique characteristics developed over decades of use. The subtleties of these microphones and their aging components shape the way they interact with different preamps and compressors.
After making over a hundred records at Blackbird over the last eight years, I’ve grown quite familiar with a good portion of our 1,800-plus vintage mics, like Telefunken 251s, AKG C12s, Neumann U 47s and KM 84s, Shure SM7s and SM57s, RCA 44s and 77s, and Royer R-121s. These are the very same mic models that most modeling mics are trying to capture. But experience has taught me that not all microphones sound identical even if they are the same make and model (and year). Also, the same vintage microphone can sound different on different days depending on temperature, humidity, and the voltage from the wall (that’s why Blackbird has its own regulated power and all the studios strive for consistent temperature and humidity year-round).
For home studios and smaller production environments, microphone-modeling systems can be a game changer. You’ll get a wide range of high-end microphone sounds without the need for a large microphone collection, and the ability to change microphone models after the fact gives budding producers and engineers greater confidence and flexibility in their work.
In reality, most users find that the convenience, cost savings, and versatility offered by modeling systems far outweigh any potential shortcomings. Finally, keep in mind that even though the mic “profile” you choose (U 47, U 67, SM7, etc.) will be consistent day in and day out, the modeling mic itself is also still a mic and will require you to be mindful of these same issues I mentioned above in order for your mic “profile” to be as accurate as possible.
Until next time, namaste.
