The post-punk 6-string hero takes a deep dive into sonic surrealism with his new album, a loop-driven collection of riveting soundscapes called Eight Dream Interpretations for Solo Electric Guitar Ensemble.
If you ever find the opening to ask a composer or producer what it means to “paint with sound,” be prepared to frame the question in as many different ways as there are colors in the visible spectrum. Inspired by synaesthesis? Could be. Maybe a deep dive into abstract free-form improv? Sure, always worth a shot. What if you commit to exotic tunings or unconventional music theory? Or how about a mash-up of prepared instruments with some radical effects processing and tape manipulation?
We can do this all day, but before we lean into an “all of the above” approach, consider this: The only limit, really, is your imagination—or, more suggestively, your dreams. “There’s a way to get to that psychedelic state without actually taking psychedelics, which is useful,” Roger Clark Miller explains, with just a glint of conspiratorial humor. Given his illustrious history as a post-rock guitar guru and multi-instrumentalist with influences that range from ’60s acid rock to avant-shred to modern classical, Miller is intimately familiar with what it takes to push any and all boundaries in search of the music he hears in his head.
“The first time that I actually did something interesting with it was back in art school,” he recalls, paying tribute to his teacher Denman Maroney, a legendary jazz outsider known for his work with prepared piano. “He saw my interests and thought I’d probably like surrealism. Up until then, my idea of surrealism was taking acid [laughs].”
After reading André Breton’s surrealist manifestos (the second one, in particular, which touches on dreams as a creative reservoir), he set about applying the techniques to making music—and ran into a roadblock. “Breton actually said because music isn’t so specific, it can’t be surrealistic. And that kind of pissed me off. I was looking for a way to compose, and I didn’t want to use what had come before. I thought, well, if I make music based on dreams, then I can create a surrealistic music, and bypass Breton’s megalomania—as much as I respect him! This gave me access to a very organic structure. Everybody dreams, and there are forms to it.”
Miller’s jauntily titled Eight Dream Interpretations for Solo Electric Guitar Ensemble, released earlier this year on the Cuneiform label, is in many ways the culmination of the technique he started developing back in 1975, when he created his first piece for solo violin. Miller has kept dream journals for decades, and uses them primarily as a non-linear source for ideas that he fleshes out into musical compositions. (“I don’t actually hear music unless it was part of the dream,” he points out.)
“This kind of music rewards attentive listening because it’s really composed and thought-out, so you’re not gonna be bored.”
If all that sounds a bit abstract and even esoteric, keep in mind this is the very same guy who co-founded Mission of Burma, one of the most viscerally immediate post-punk bands to come out of Boston’s raucous underground scene in the late ’70s and early ’80s. Back then, Miller adopted the much reviled Fender Lead I as his axe of choice, figuring he could put his personal stamp on it. As it turned out, the guitar’s cheaper construction and single split humbucker was perfect for sculpting an angular, aggressively jagged, but still bluesy sound through a vintage Marshall JMP-50 combo.
Miller was also a founding member of the somewhat kinder and gentler group Birdsongs of the Mesozoic, in which he played piano. (Due to his early struggles with tinnitus, he had to bow out of Burma in 1983, but the band reunited in 2002 for four more albums.) All this history and plenty more feeds back into the making of the Dream Interpretations, for reasons that Miller loves to elucidate.
Miller’s goal for his new album was to bring his surrealistic dreams in sound to life. His most recent tools for this task include three Rogue RLS-1 lap steel guitars and a Boomerang III looping system, which he uses in tandem with the Side Car controller footswitch.
“With my friend Martin Swope,” he says, name-checking Mission of Burma’s resident sound technician and live-tape-looping scientist, “like everybody, we were pretty fascinated with Brian Eno’s work at that time. Martin wanted to do a Robert Fripp and Eno style thing, so he had me play this amorphic, modal piano piece that I wrote, and he made these guitar loops going around and around. That was for Birdsongs, but he and I had worked like that on the song ‘New Disco’ [for Burma]. That’s how he became part of the band.”
Over the years, Miller folded what he learned from Swope into the sound he was chasing. In the early ’80s, he acquired an Electro-Harmonix 16-second digital delay. “It’s truly one of the most unique devices ever made,” he says. “It’s so unique that I used it as my pivot for quite a few years. I still have it, but its biggest drawback is the memory. If you make something longer than a two-second loop, the fidelity degrades. Back in 1983, memory was not cheap.”
“With looping, you can hear a sound and you don’t know when it happened or what instrument did it.”
The effect figured prominently in the making of his 1995 solo slab, Elemental Guitar, which he tracked using what was then a recently acquired ’62 Strat reissue. The album also features two pieces, “Dream Interpretation No. 7” and “Dream Interpretation No. 8,” that Miller considers to be successful precursors to his current album.
More than 25 years later, Eight Dream Interpretations opens with “Dream Interpretation No. 16,” a chilling excursion that suggests a serpentine path being resumed, although much has changed in the interim. For starters, Miller has added three Rogue RLS-1 lap steel guitars to his arsenal: one tuned to unison E and used exclusively for slide parts, and the other two prepared with alligator clips and strung with different gauges to capture a wider palette of tones. He’s also mothballed the Electro-Harmonix in favor of a Boomerang III looping system, which he uses in tandem with the Side Car controller footswitch.
Roger Clark Miller’s Gear
Besides looping and other effects, plus his trusty Stratocaster, Miller relies on a trio of lap steels to create his celestial soundscapes—in three different tunings.
Photo by Roger Clark Miller
Guitars
- 1990 Fender Stratocaster ST62 reissue (made in Japan)
- Rogue RLS-1 lap steel (three: one tuned to unison E and used as a slide guitar, two others prepared with alligator clips)
Amps
- Fender Deluxe Reverb (two)
- Sunn bass head with 610L cabinet
- Peavey Classic 50 410 combo
- Walrus Audio MAKO Series ACS1 Amp and Cab Simulator
Effects
- Electro-Harmonix 16-Second Digital Delay
- Boomerang III Phrase Sampler with Side Car controller
- TC Electronic Brainwaves Pitch Shifter
- TC Electronics Rush Booster
- Electro-Harmonix East River Drive
- Source Audio Kingmaker Fuzz
- Ernie Ball stereo volume pedal
Strings & Picks
- Ernie Ball Regular Slinky (.010–.46; Strat)
- D’Addario EXL 157 (.014–.069; lap steel)
- D’Addario Medium EXL 160 (.050–.105; lap steel)
- Dunlop Max-Grip .73 mm
Along with his trusty Strat, when Miller seats himself behind the Rogues it’s as though he’s strapping in for an interstellar journey at the helm of a homemade time machine. And the music comes across that way, from the dueling dive-bombing waves and high-pitched jet washes of “No. 19” to the softly percussive melodies and clean, pitch-shifted guitar lines of “No. 18.” (The tracks are sequenced as any album would be, not in numerical order, but according to the listening experience Miller wants to establish.) Outfitted with various effects that he dials in with the precision of a surgeon, Miller literally choreographs each move he makes to create the music. It’s mesmerizing to watch him in the video, directed by filmmaker Jesse Kreitzer, that accompanies “No. 17”—a wildly cinematic and soundscape-y piece that’s driven by a persistent, pulsating rhythm and a haunting sci-fi melody straight out of vintage Doctor Who.
When asked about influential recordings that have inspired him, Miller’s tastes run eclectic, to say the least. Fred Frith’s groundbreaking Guitar Solos album, an experimental classic, is “just an amazing work. I learned about using alligator clips from that album.” And then there’s the 1982 minimalist epic Descending Moonshine Dervishes by Terry Riley (“the first honest looper,” he says). But when it comes to specific guitar players, there are two in particular who move him to rapture.
The reunited Mission of Burma—guitarist Roger Miller, drummer Peter Prescott, and bassist Clint Conley—at the All Tomorrow’s Parties festival in London, England, in 2004.
Photo by Neonwar/Courtesy of Wikipedia Commons
“See, I’m a little older than some of your readers here,” he warns, “but I came to my creative start during psychedelia and the British Invasion, so my heroes were Syd Barrett and Jimi Hendrix. I mean, Jimi was like a bolt of electricity from who knows where. He embraced the electric guitar as an instrument that could explain all sorts of alternate realities, and he wasn’t the first to use feedback, but he walked into it with complete conviction and cut a path for others to follow.
“And whereas Hendrix was a true guitar master, Barrett was considerably less skilled, but his vision, when operating on all cylinders, just transcended the limitations. For him, sound and vision were more important than technique. He was also a painter, and that may well have had something to do with it—painting with sound indeed! His solo on ‘Take Up Thy Stethoscope and Walk’ was once described to me as the ugliest guitar playing anyone had ever heard. Not for me!”
“I came to my creative start during psychedelia and the British Invasion, so my heroes were Syd Barrett and Jimi Hendrix.”
With ears wide open, Miller is constantly exploring new directions. His most recent composition, the nearly self-explanatory Music for String Quartet and Two Turntables, has just been recorded with members of Boston’s Ludovico Ensemble. He also has a new album in the can with Trinary System, the rock trio he founded in 2013, planned for release next year. Whether he’s painting with sound or testing the very elasticity of time, his multidisciplinary method of mining his dreams and looping the sonic events of his waking life continues to yield dividends.
“I don’t really think about it per se,” he clarifies, “but certainly with looping, you can hear a sound and you don’t know when it happened or what instrument did it. That’s when looping messes with time. And then in dreams, time is elastic, too. So perhaps it’s a mixture of those things. To me, this kind of music rewards attentive listening because it’s really composed and thought-out, so you’re not gonna be bored. But it does also work for me as an atmospheric, swirling clouds-in-the-room kind of thing. That makes me happy.”
Mission of Burma - Laugh The World Away (Live on KEXP)
We’re giving away more gear! Enter Stompboxtober Day 24 for your chance to win today’s pedal from Maxon!
Maxon OD-9 Overdrive Pedal
The Maxon OD-9 Overdrive Effects Pedal may look like your old favorite but that's where the similarity ends. Improved circuitry with a new chip yields the ultra-smooth dynamic overdrive guitarists crave. Drive and Level controls tweak the intensity and volume while the Hi-Boost/Hi-Cut tone controls adjust brightness. Features true bypass switching, a die-cast zinc case, and 3-year warranty. From subtle cries to shattering screams, the Maxon OD-9 delivers a huge range of tones.
Features
Improved circuitry with a new chip yields ultra-smooth dynamic overdrive
Drive and Level controls tweak the intensity and volume
Hi Boost/Hi Cut tone controls adjust brightness
True bypass switching
Die-cast zinc case
AC/DC operation (order optional Maxon AC210N adapter)
Product Specs
Input: 1/4" mono jack
Output: 1/4" mono jack
Power: 9V DC, 6 mA, center pin minus (not included)
Dimensions: (WxDxH) 74 mm x 124 mm x 54 mm
Weight: 580g
Here’s part two of our look under the hood of the funky rhythm guitar master’s signature 6-string.
Hello and welcome back to Mod Garage. In this edition, we’re continuing our journey through the Fender Cory Wong Stratocaster wiring, bringing it all together.In the previous installment, the last feature on the funky 6-stringer’s signature axe that we discussed was the master volume pot and the corresponding treble-bleed circuit. Now, let’s continue with this guitar’s very special configuration of the tone pots.
Tone pot with Fender Greasebucket tone system:
This 250k tone pot is a standard CTS pot with a 90/10 audio taper found in all U.S.-built Fender guitars. The Cory Wong guitar uses the Fender Greasebucket system, which is added to the pot as a ready-to-solder PCB. The Greasebucket PCB is also available individually from Fender (part #7713546000), though you can use conventional electronic parts for this.
Fender introduced this feature in 2005 on some of the Highway One models and some assorted Custom Shop Strats. The Greasebucket name (which is a registered Fender trademark, by the way) is my favorite of Fender’s marketing names, but don’t let it fool you: Your tone will get cleaner with this modification, not greasy and dirty.
According to Fender, the Greasebucket tone circuit reduces high frequencies without adding bass as the tone knob is turned down. Don’t let that description confuse you. A standard Strat tone control does not add any bass frequencies! As you already know, with a passive system you can’t add anything that isn’t already there. You can reshape the tone by deemphasizing certain frequencies and making others more prominent. Removing highs makes lows more apparent and vice versa. In addition, the use of inductors (which is how a passive pickup behaves in a guitar circuit) and capacitors can create resonant peaks and valleys (band-passes and notches), further coloring the overall tone.
Cory Wong bringing the funk onstage.
This type of band-pass filter only allows certain frequencies to pass through, while others are blocked. The standard tone circuit in a Strat is called a variable low-pass filter (or a treble-cut filter), which only allows the low frequencies to pass through while the high frequencies get sent to ground via the tone cap.
The Greasebucket’s band-pass filter is a combination of a high-pass and a low-pass filter. This is supposed to cut high frequencies without “adding” bass, which has mostly to do with the resistor in series with the pot. That resistor means the control will never get to zero. You can get a similar effect by simply not turning the Strat’s standard tone control all the way down. (The additional cap on the wiper of the Greasebucket circuit complicates things a bit, though; together with the pickups it forms an RLC circuit, but I really don’t want to get into that here.)
The standard Fender Greasebucket tone system is used in the Cory Wong Strat, which includes a 0.1 μF cap and a 0.022 uF cap, along with a 4.7k-ohm resistor in series. These are the values used on the PCB, and without the PCB it looks like the illustration at the top of this column.
Push-push tone pot with preset overwriting function:
The lower tone pot assigned to the bridge pickup is a 250k audio push-push pot with a DPDT switch. The switch is used to engage a preset sound by overwriting the 5-way pickup-selector switch, no matter what switching position it is in. The preset functionality has a very long tradition in the house of Fender, dating back to the early ’50s, when Leo Fender designed a preset bass sound on position 3 (where the typical neck position is on a modern guitar) of the Broadcaster (and later the Telecaster) circuit. Wong loves the middle-and-neck-in-parallel pickup combination, so that’s the preset sound his push-push tone pot is wired for.
The neck pickup has a dedicated tone control while the middle pickup doesn’t, which is also another interesting feature. This means that when you hit the push-push switch, you will engage the neck and middle pickup together in parallel, no matter what you have dialed in on the 5-way switch. Hit the push-push switch again, and the 5-way switch is back to its normal functionality. Instead of a push-push pot, you can naturally use a push-pull pot or a DPDT toggle switch in combination with a normal 250k audio pot.
Here we go for the wiring. For a much clearer visualization, I used the international symbol for ground wherever possible instead of drawing another black wire, because we already have a ton of crossing wires in this drawing. I also simplified the treble-bleed circuit to keep things clearer; you’ll find the architecture of it with the correct values in the previous column.
Cory Wong Strat wiring
Courtesy of singlecoil.com
Wow, this really is a personalized signature guitar down to the bone, and Wong used his opportunity to create a unique instrument. Often, signature instruments deliver custom colors or very small aesthetic or functional details, so the Cory Wong Stratocaster really stands out.
That’s it! In our next column, we will continue our Stratocaster journey in the 70th year of this guitar by having a look at the famous Rory Gallagher Stratocaster, so stay tuned!
Until then ... keep on modding!
